Off-Road Trailers
Click images to enlarge:
When you take your trailer off-road make sure you have the confidence in knowing that your trailer was designed and built with off-road conditions in mind. And this model certainly was.
It is made tough for off-road conditions and includes deep sides as standard along with heavier suspension, a longer drawbar, off-road axle and 16’ x 6 stud hubs.
This trailer really is toughness squared. Our off-road trailers are value packed with features designed for extra towing comfort and performance and come with unbeatable 2 year Warranty and FREE 2 years Roadside Assist.
Every trailer is packed with value:
- galvanised steel construction
- new wheels and tyres
- checkerplate floor
- full chassis
- magnetic trailer plug
Plus, your trailer comes set to fit a cage or rack if needed with four smartly designed corner posts included.
Other features include heavy duty tie rails all round, a full rear cross member, and an impressive 750kg Aggregate Trailer Mass (ATM).
Off-Road Extras Also Available
Options such as side steps, off-road couplings, jerrycan holders, gas bottle holders, toolboxes, brakes, and shackle springs are also available.
In addition the usual accessories such as cages, covers, tradesman’s and pantec tops, ladder racks, drop-in bike racks, jockey wheels and spare wheels are available on all trailers.
Off-Road trailers are also available in hot dip galvanised finish.
Specifications
Floor
Checkerplate Galvanised (Galvaneal)
Chassis
Galvanised SHS
Drawbar
Galvanised RHS
Body Panels
400mm High Galvanised (Galvaneal) Steel
Axle(s)
45mm Square Solid High Tensile Steel
Hubs(s)
200mm Cast Steel Trailer Hubs
Bearings
Slimline
Wheels & Tyres
16” New Wheels & Tyres
Tilt
Square Tie Rails
Tie Rails
Tie Rails
Lights
LED
Jockey Wheel Clamp
Included
Coupling
Zinc Plated Quick Release Coupling
Springs
6 Leaf Slipper Springs
These trailers are available to Rent Then Buy.
Fill in your details in the enquiry form to request more information about our Rent Then Buy options.
Dimensions
Size | H | L1 | L2 | L3 | W1 | W2 |
6 x 4 | 500mm | 1800mm | 1580mm | 3380mm | 1200mm | 1720mm |
7 x 4 | 500mm | 2100mm | 1560mm | 3660mm | 1200mm | 1720mm |
7 x 5 | 500mm | 2100mm | 1500mm | 3600mm | 1500mm | 2020mm |
8 x 5 | 500mm | 2400mm | 1500mm | 3900mm | 1500mm | 2020mm |
